 To configure the GW User Info table in the Web interface:
1. Open the GW User Info Table page (Configuration tab > VoIP menu > SIP
Definitions > User Information > GW User Info Table).
2. Click Add: the following dialog box appears:
Figure 46-2: GW User Info Table in Web Interface
3. Configure the GW User Info table parameters according to the table below.
4. Click Submit.
5. To save the changes to flash memory, see ''Saving Configuration'' on page 606.
To register a user, select the user's table entry, and then from the Action button's drop-
down list , choose Register. To un-register a user, select the user, and then from the
Action button's drop-down list , choose Un-Register.
Table 46-2: GW User Info Table Parameter Descriptions
Parameter Description
Index
[GWUserInfoTable_Index]
Defines an index for the new table record.
PBX Extension
[GWUserInfoTable_PBXExtension]
Defines the PBX extension number.
The valid value is a string of up to 10 characters.
Global Phone Number
[GWUserInfoTable_GlobalPhoneNumber]
Defines the "global" phone number for the IP side.
The valid value is a string of up to 20 characters.
Display Name
[GWUserInfoTable_DisplayName]
Defines the Caller ID of the PBX extension.
The valid value is a string of up to 30 characters.
Username
[GWUserInfoTable_Username]
Defines the username for registering the user when
authentication is necessary.
The valid value is a string of up to 40 characters.
Password
[GWUserInfoTable_Password]
Defines the password for registering the user when
authentication is necessary.
The valid value is a string of up to 20 characters.
Status (Read-only field) Displays the status of the user -
"Registered" or "Not Registered".
