AudioCodes Mediant 500L MSBR

User's Manual 902 Document #: LTRT-10466
Mediant 500L MSBR
Parameter Description
Web/EMS: SMDI Timeout
[SMDITimeOut]
Defines the time (in msec) that the device waits for an SMDI Call
Status message before or after a Setup message is received. This
parameter synchronizes the SMDI and analog CAS interfaces.
If the timeout expires and only an SMDI message is received, the
SMDI message is dropped. If the timeout expires and only a Setup
message is received, the call is established.
The valid range is 0 to 10000 (i.e., 10 seconds). The default is 2000.
Message Waiting Indication (MWI) Parameters
Web: MWI Off Digit Pattern
EMS: MWI Off Code
CLI: mwi-off-dig-ptrn
[MWIOffCode]
Defines the digit code used by the device to notify the PBX that there
are no messages waiting for a specific extension. This code is added
as prefix to the dialed number.
The valid range is a 25-character string.
Web: MWI On Digit Pattern
EMS: MWI On Code
CLI: mwi-on-dig-ptrn
[MWIOnCode]
Defines the digit code used by the device to notify the PBX of
messages waiting for a specific extension. This code is added as
prefix to the dialed number.
The valid range is a 25-character string.
Web: MWI Suffix Pattern
EMS: MWI Suffix Code
CLI: mwi-suffix-pattern
[MWISuffixCode]
Defines the digit code used by the device as a suffix for 'MWI On Digit
Pattern' and 'MWI Off Digit Pattern'. This suffix is added to the
generated DTMF string after the extension number.
The valid range is a 25-character string.
Web: MWI Source Number
EMS: MWI Source Name
CLI: mwi-source-number
[MWISourceNumber]
Defines the calling party's phone number used in the Q.931 MWI
Setup message to PSTN. If not configured, the channel's phone
number is used as the calling number.
CLI: mwi-subs-ipgrpid
[MWISubscribeIPGroupID]
Defines the IP Group ID used when subscribing to an MWI server. The
'The SIP Group Name' field value of the IP Group table is used as the
Request-URI host name in the outgoing MWI SIP SUBSCRIBE
message. The request is sent to the IP address defined for the Proxy
Set that is associated with the IP Group. The Proxy Set's capabilities
such as proxy redundancy and load balancing are also applied to the
message.
For example, if the 'SIP Group Name' field of the IP Group is set to
"company.com", the device sends the following SUBSCRIBE
message:
SUBSCRIBE sip:company.com...
Instead of:
SUBSCRIBE sip:10.33.10.10...
Note: If this parameter is not configured, the MWI SUBSCRIBE
message is sent to the MWI server as defined by the MWIServerIP
parameter.
[NotificationIPGroupID] Defines the IP Group ID to which the device sends SIP NOTIFY MWI
messages.
Notes:
 This is used for MWI Interrogation. For more information on the
interworking of QSIG MWI to IP, see Message Waiting Indication
on page 444.
 To determine the handling method of MWI Interrogation messages,
use the TrunkGroupSettings_MWIInterrogationType, parameter (in
the Trunk Group Settings table).
