7. Advanced
7.9.2 Projector address
How to change the projector address ?
1. See the Setup section.
7.9.3 Orientation
How to set up the orientation ?
1. See the Setup section.
7.9.4 Frustum resolution
Description
The horizontal resolution of the frustum can be selected to two different values, each leading to different internal overlap and geom-
etry settings:
1184 pixels (default setting)
1296 pixels
The value must be set according to the input resolution.
How to change frustum resolution?
1. Press MENU to activate the Tool bar
2. Press to select the Installation item
3. Press to pull down the Installation menu
4. Use or to select F rustum resolution
5. Press to pull down the Frustum resolution menu
6. Use or to select the desired value
Image 7-153
7. Press ENTER
7.9.5 Network settings
How to set the network ?
1. See the Comm unications section.
7.9.6 Automatic shutdown
How to switch to Automatic Shutdown mode?
1. Press MENU to activate the Menu bar
2. Press to select the Installation item
3. Press to Pull down the Installatio n menu
4. Use or to select Automatic Shutdown
5. Press to select the Autom atic Shutdown item
R59770198 BARCO SIM 7D 13/02/2013
139
