Barco SIM 7D User Manual

7. Advanced
The file is selected and will be loaded in the future.
To delete the forced file, go to the desired input and press ENTER.
7.5 Geometry
Overview
• Introduction
• Geometry files
• Accessing the Geometry menu
• Geometry distortions
• Load
•Edit
• Rename a Geometry File
• Copy a Geometry File
• Delete a Geometry File
The geometry adjustment is done on the hand held remote control unit RACU. The Geometry a
djustment menu
on the projector should only be used for demo purposes.
See the dedicated System manual for more information.
7.5.1 Introduction
What can be done ?
With the geometry corrections, this projector can be used in a wide variety of curved and flat-screen applications, ranging from flat
or straightforward cylindrical displays to the wildest shapes that can be imagined: by pre-distorting the image inside the projector, a
correct geometry can be achieved on curved screens, without requiring additional computational power on the IG’s side.
7.5.2 Geometry files
Description
A geometry file contains the geometry corrections. The projector
’s memory contains a list of files created for demo purposes e.g. to
demonstrate the warping capabilities of the projector. These files are called standard files.
The active filecanalwaysbeeditedinordertofit exactly the screen shape. Editing a standard file will automatically create a custom
file.
The file notation in the Ge ometry files menu describes a file path.
For example : /Standard/Dist_file1.xml
/Standard/Dist_file1.xml
Type of file : standard or custom
file name
file extension = xml
Image 7-29
Geometry file notation
Standard file directory, also the type of file : Custom or Standard
Dist_file1 file name
xml
file extension
R59770198 BARCO SIM 7D 13/02/2013 67
