Barco SIM 7D User Manual

4. Installation
Projector
Screen
Horizontal shift in nominal position Horizontal shift : -70%
Projector
Screen
Image 4-12
Projector Projector
Screen
Vertical shift in nominal position
Screen
Screen
Vertical shift : +100% Vertical shift : -100 %
Projector
Image 4-13
4.5.4 Installing the lens and adjusting the Scheimpflug
WARNING: In case of a projector with NVG option, do not insert your fingers in the lens holder if the lens is
removed. They could get hit by the smearing reduction wheel!
Image 4-14
CAUTION: Make sure that the projection lens and the interpolation lens are a matched set. Replacing any one
of these units requires the re
placement of the other.
Each of the lenses have Scheimpflug adjustment possibility!
20 R59770198 BARCO SIM 7D 13/02/2013
