Barco SIM 7D - Installation

4. Installation
4. INSTALLATION
Overview
• Dimensions
• Fixation points at the bottom of the projector
• Projector tilt
• RCU battery installation
• Lens installation
• Projector configuration
• Connections
• Controls
4.1 Dimensions
Projector dimensions and weight
Dimensions are given in mm and inch (1 inch = 25.4 mm)
Weight (without lens) : approximately 27.5 kg (60.6 lbs)
