Field Description
Select the configuration mode of the interface.
Possible values:
• .## (default value): The interface is not assigned for
a specific purpose.
• *## E03)!: This option only applies for routing inter-
faces.
You use this option to assign the interface to a VLAN. This is
done using the VLAN ID, which is displayed in this mode and
can be configured. The definition of a MAC address in MAC
Address is optional in this mode.
VLAN ID Only for Interface Mode = *## E03)!
This option only applies for routing interfaces. Assign the inter-
face to a VLAN by entering the VLAN ID of the relevant VLAN.
Possible values are (default value) to .
MAC Address Enter the MAC address associated with the interface. For virtual
interfaces, you can use the MAC address of the physical inter-
face under which the virtual interface was created by activating
Use built-in, but VLAN IDs must be different. You can also al-
locate a virtual MAC address. The first 6 characters of the MAC
are preset (but can be changed).
If Use built-in is active, the predefined MAC address of the al-
located physical interface is used.
Use built-in is activated by default.
Fields in the Basic IPv4 Parameters menu.
Field Description
Security Policy Select the security settings to be used with the interface.
Possible values:
• * (default value): All IP packets are allowed through
except for those which are explicitly prohibited..
• .: Only those packets are transmitted that can be
attributed to a connection that has been initiated from a trus-
bintec elmeg GmbH
7 LAN
bintec RS Series 137
