Field Description
You can specify the Link Prefix of an IPv6 address. This prefix
must end with 88. Its predetermined length is .
Fields in the Host Address menu.
Field Description
Generation Mode
Determine if the Host Identifier of the IPv6 address is to be
automatically derived from the MAC address through EUI-64.
The function is activated by selecting "1 .
The function is enabled by default.
EUI-64 triggers the following process:
• The hexadecimal 48 bit MAC address is split into 2 x 24 bit.
• <<< is inserted into the created gap in order to obtain 64 bit.
• The hexadecimal notation of the 64 bit is converted to a bin-
ary notation.
• Bit no. 7 of the first 8 bit field is set to .
Static Addresses
Independently of the automatic creation described under Gen-
eration Mode, you can manually specify the Host Identifier of
one or more IPv6 addresses with Add. Its predefined length is
. Start any entry with 88 .
The fields in the Advanced menu are part if the prefix information sent inside of Router Ad-
vertisements if Advertise is enabled. The menu Advanced consists of the following fields:
Fields in the Advanced IPv6 Settings menu
Field Description
On Link Flag Select whether the On-Link Flag (L-Flag) should be set. This al-
lows the host to enter the prefix from the prefix list.
The function is activated by selecting * .
The function is enabled by default.
Autonomous Flag Select whether the Autonomous Address Configuration Flag
(A-Flag) should be set. This allows the host to use the prefix
and the 64 bit interface ID, to derive its address.
The function is activated by selecting * .
bintec elmeg GmbH
7 LAN
bintec RS Series 143
