Field Description
tification number of the virtual channel. A virtual channel is the
logical connection for the transport of ATM cells between two or
more points. Note your provider's instructions.
Possible values are & to &.
The default value is 32.
Encapsulation Only for Provider = . $
Select the encapsulation to be used. Note your provider's in-
structions.
Possible values (in accordance with RFC 2684):
• 006 :# <6 (Default value for Ethernet over
ATM : Is only displayed for Type = 3*'.
Bridged Ethernet with LLC/SNAP encapsulation without
Frame Check Sequence (checksums).
• 006 :# <6: only displayed for Type =
3*'.
Bridged Ethernet with LLC/SNAP encapsulation with Frame
Check Sequence (checksums).
• ) - (default value for Routed Protocols over ATM): Is
only displayed for Type = A %1 3*'.
Encapsulation with LLC/SNAP header, suitable for IP routing.
• 006: only displayed for Type = 3*'.
Encapsulation with LLC header.
• E6 '1+1?# (default value for PPP over ATM):
Bridged Ethernet without additional encapsulation (Null En-
capsulation) with Frame Check Sequence (checksums).
Fields in menu Ethernet over ATM Settings (appears only for Type = Ethernet over
ATM)
Field Description
Default Ethernet for
PPPoE Interfaces
Only for Type = 3*'
Select whether this Ethernet-over-ATM interface is to be used
for all PPPoE connections
13 WAN bintec elmeg GmbH
340 bintec RS Series
