Fields in the Software and Configuration Options menu.
Field Description
Action
Select the action you wish to execute.
After each task, a window is displayed showing the other steps
that are required.
Possible values:
• ) 3% (default value):
• ?+ %$#: The configuration file Current
File Name in Flash is transferred to your local host. If you
click the Go button, a dialog box is displayed, in which you
can select the storage location on your PC and enter the de-
sired file name.
• + %$#: Under Filename select a config-
uration file you want to import. Please note: Click Go to first
load the file under the name " in the flash memory for the
device. You must restart the device to enable it.
Please note: The files to be imported must be in CSV format!
• 6+( %$#: The configuration file in the Source
File Name field is saved asDestination File Name.
• 51 %$#: The configuration in the Select
file field is deleted.
• A %$#: The configuration file in the Se-
lect file field is renamed to New File Name.
• A "%9+ %$#: Only if, under Save
configuration with the setting %$#
"%9 + + " %$# the current
configuration was saved as boot configuration and the previ-
ous boot configuration was also archived.
You can load back the archived boot configuration.
• 51 $7/$7: The file in the Select file
field is deleted.
• + 1##: You can import additional language ver-
sions of the GUI into your device. You can download the files
to your PC from the download area at
www.bintec-elmeg.com and from there import them to your
device
bintec elmeg GmbH
18 Maintenance
bintec RS Series 547
