Installing the Handset (Optional) (MF8580Cdw / MF8550Cdn / MF8280Cw
Only)
Install the optional handset on the machine. Have all of the included parts ready before you start installing.
Remove the two covers.
Insert the plugs with pins into the holes on the handset cradle.
NOTE:
Do not fully insert the pins into the plugs at this point.
Insert the plugs (with the cradle) into the holes on the machine.
Carefully push the pins into the plugs as far as they will go.
Place the handset on the cradle.
1
2
3
4
5
