Cisco D9887B User Manual

Video Output (1 RGBHV/YPbPr, 1 Composite) Option
78-4043743-01 Rev A 211
Connector:
High Density 15-pin D-sub, female
Impedance:
75 ohms, +/-10%; 1 k ohm for syncs
Return Loss:
> 20 dB, 30 KHz – 30 MHz
Frequency Response:
Y = 30 KHz – 30 MHz, +/-0.2 dB ripple
PbPr = 30 KHz – 15 MHz, +/-0.2 dB ripple
H/V Sync:
4 Vpp into 1 Mohm, negative polarity
Composite Video Out –
Number of Outputs:
1 (NTSC/PAL)
Connector:
BNC, female
Impedance:
75 ohms, +/-10%
Return Loss:
> 25 dB
Frequency Response:
DC to 6.0 MHz
Amplitude:
140 IRE (1.0 Vpp), +/-2 IRE
NTSC -
Standard:
ANSI/SMPTE 170M-1994; CCIR656
Format, Frame rate
525 lines, 29.97 Hz (480i)
Setup (pedestal):
On/Off, selectable
Closed Caption:
Enable/Disable, selectable
CC Standard:
EIA-608B
PAL -
Standard:
ITU-R.BT.470-6
Format, Frame rate: 625 lines, 25.00 Hz
Genlock -
Line and Pixel Adjustment
Color Phase Adjustment (Video Output
(2 HD/SD-SDi, 1
RGBHV/YPbPr?Composite) option
only)
