Cisco D9887B User Manual

Appendix B
Specifications
206 78-4043743-01 Rev A
D9887B receiver – base unit
Includes:
Display, keypad, embedded controller,
Chassis/case, Power Supply/line cord
System –
Display type:
VFD (Vacuum Fluorescent Display)
Display Configuration:
4 lines x 20 characters
Keypad:
Membrane switches
Front Panel Lockout:
Password control, up to 10 alpha-numeric
characters (no punctuations or spaces allowed)
Configurations Allowed:
Single RDS – 8-Slot (Configuration 1)
Dual RDS – 4-Slot each RDS (Configuration 2)
Rear panel:
Eight available slots
Six I/O interface slots
Two video output slots (Configuration
dependent)
Remote Operation/Update Interface –
Type:
Ethernet, 10/100
Rear panel indicators:
Link (Green LED), Activity (Amber LED)
Connector:
RJ45
Serial Remote operation interface –
Type:
RS232
Protocol:
115, 8, N, 1
Connector:
9-pin D-sub, male
Front Panel Indicators –
Input LED:
Green indicates valid input on selected input
Off indicates no valid signal on the selected input
Constant Blinking Green for Configuration 2
units indicates one valid input and one invalid
input
Error LED:
Red indicates error is occurring
Off indicates no errors detected
AC Power –
Operating Voltage:
95–135 VAC or 180–265 VAC
