Cisco D9887B User Manual

Video Output (2 SDI, 1 RGBHV/YPbPr/Composite) Option
78-4043743-01 Rev A 219
Video Output (2 SDI, 1 RGBHV/YPbPr/Composite)
Option
SDI outputs 1 and 2 can be set to either HD-SDI or SD-SDI independently.
General –
Connector:
2 Female BNC
Impedance:
75 ohms ±10%
Output Connectors:
2 – SDI, 1 – RGBHV/YPbPr/Composite
(Composite/YPbPr output with breakout cable only)
Genlock –
SDI:
Line and Pixel Adjustment
Composite:
Line, Pixel, Color Phase Adjustment
SDI (Serial Digital Interface)
Video Out –
Display Capability:
Can display HD-SDI and SD-SDI simultaneously
HD-SDI Standard:
SMPTE-292M
SMPTE-274M (1080i, 29.97 Hz)
SMPTE-296M (720p, 59.94 Hz)
SD-SDI Standard:
ITU-BT.601/SMPTE-S259M
Data Bit Rate:
SD-SDI – 270 Mbps
HD-SDI – 1.485 Gbps
Display Modes:
Letterbox, cropped, anamorphic
Embedded Audio Format:
SD-SDI – SMPTE-272M
HD-SDI – SMPTE-299M
Sample Rates Supported:
48 kHz
Sample Rate Out:
48 kHz
Output Squelch:
Selectable – Enable/Disable (when no input is
detected, output is muted)
Number of Embedded Audio
Channel Pairs:
8 (4 groups, each with 2 pairs)
Audio Types Supported:
Dolby Digital, MPEG-2 layer 1 and 2, or PCM
Dolby E, with Audio Output (Dolby E, AES Digital,
Analog) option
Embedded Audio Control:
Selectable – "type"/disable (each pair independently
controlled)
