Dual MPEG over IP Input/ UDP Output Option
General Information
Install Location: Installs in 1–2 through 1–4 and/or 2–2 through 2–4.
I/O: (2) 10/100/1000 Auto-negotiating Base-T RJ-45 Ethernet Port
Supported Formats: Receive UDP or RTP Multicasts and Unicasts. Transmit: UDP
only
Description: This card encapsulates the TS from the bus and will transmit IP
streams. It can also take in IP streams and place them on the bus for an ASI/310M
card and/or a decoder. Up to two multicasts can be subscribed to, allowing for a
backup multicast to be chosen and two mirrored unicasts can be transmitted to allow
for redundancy. The two physical connectors can be configured independently.
Menu Control
This menu is used to setup the IP address, Subnet Mask, and Gateway for the
MPEG/IP card. These settings need to be set to proper values for the network that
the D9887B receiver is being used on. These values can usually be obtained from the
local network administrator.
1 Press the Menu button.
2 Use the Up and Down buttons to move the cursor to "MPEG/IP NetCfg," then
press the Enter button.
3 Select "Port 1" or "Port 2," and then press the Enter button.
