Cisco D9887B User Manual

Appendix B
Specifications
210 78-4043743-01 Rev A
Video Output (1 RGBHV/YPbPr, 1 Composite)
Option
Analog Video General -
Video Standards:
SMPTE-274M (1080i and 1080p)
SMPTE-296M (720p)
SMPTE-253M (480p)
SMPTE-170M (480i)
(Reference: EIA 770.2 and 770.3)
Output Formats:
1920 x 1080 Interlaced (1080i)
1920 x 1080 Progressive (1080p)
1280 x 720 Progressive (720p)
720 x 480 Progressive (480p)
720 x 480 Interlaced (480i)
Frame Rates:
1080i@ 25 Hz, 29.97 Hz, 30 Hz
720p@ 50 Hz, 59.94 Hz, 60 Hz
480p@ 59.94 Hz
480i@ 29.97 Hz
Aspect Ratio:
16x9 (fixed: 1080i, 720p)
16x9, 4x3 (selectable: 480p, 480i)
Display Modes:
HD: Letterbox, Cropped, Anamorphic
SD: Letterbox, Cropped, Anamorphic
Composite General –
Standard:
ANSI/SMPTE-170M-1994
CCIR656
PAL Standard
Output Formats:
NTSC:
480 Interlaced
PAL:
576 Interlaced
Note: Simultaneous RGB/YPbPr and Composite operation in 480i, 29.97 Hz format only.
Analog Video –
Number of Outputs:
1 (shared: RGBHV and YPbPr)
