Appendix C
Pinout Information
234 78-4043743-01 Rev A
Pinout Information
Audio Output (Dolby E, AES Digital, Analog) Option
DB-15 (Audio)
Pin
Function
1
Chan 1 (left) +
2
Chan 1 (Right) +
3
Chan 2 (Left) +
4
Chan 2 (Right) +
5
Dolby E data (Digital Output 3)
6
Chan 1 (Left) –
7
Chan 1 (Right) –
8
Chan 2 (Left) –
9
Chan 2 (Right) –
10
--
11
Ground
12
Ground
13
Ground
14
Ground
15
Dolby E ground
Video Output (2 HD/SD-SDI, 1 RGBHV/YPbPr/Composite) Option and Video
Output (2 HD/SD-SDI, 1 RGBHV/YPbPr/Comp) Option
DB-15 (RGB / YPbPr / Composite)
Pin
RGB
YPbPr
Comp
1
Red
Pr
--
2
Green
Y
--
3
Blue
Pb
--
4
--
--
--
5
Ground
Ground
Ground
