Cisco D9887B User Manual

Appendix B
Specifications
216 78-4043743-01 Rev A
Dual Input DVB-S2 Receiver Option
General –
Frequency Range:
950 MHz – 2150 MHz
Number of inputs:
2 (A and B)
Connector:
F-81 Type, Female (2)
Impedance:
75 Ohms
Return Loss:
> 9 dB
Separation:
> 65 dB
Legacy DVB-S Modulation:
QPSK
DVB-S2 Modulation:
QPSK, 8PSK
Packet size:
188 bytes
Modulation/Coding supported:
CCM (ACM & VCM not supported)
Transport Stream:
Up to 81 Mbps
Nyquist root filter roll-off factors:
.20, .25, .35
RF Input Level
-25 dBm to -65 dBm
Input RF Spectrum
Normal/Inverted Auto Detect
DVB-S –
Standard:
EN 300 421
FEC Code:
Conv. + Reed-Solomon
Viterbi soft decoder rate:
1/2
Code rates:
1/2, 2/3, 3/4, 5/6, 7/8
QPSK Symbol rate:
1-45 MSym/s
DVB-S2 –
Standard:
EN 302 307
Decoding type:
LDPC and BCH
FEC Framing Type
Normal Frames
QPSK supported rates:
1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10
8PSK supported rates:
3/5, 2/3, 3/4, 5/6, 8/9, 9/10
QPSK Symbol rate:
1-30 MSym/s
8PSK Symbol rate:
1-30 MSym/s
Carrier Loop capture range:
+/-5 MHz
Pilot:
On/Off Auto Detect
