Cisco D9887B User Manual

Video Output (2 SDI, 1 RGBHV/YPbPr/Composite) Option
78-4043743-01 Rev A 215
Uncompressed (IEC 61937)
Closed Captions:
Embedded – EIA-708B or EIA-608B
Line 21 – Enabled/Disabled (selectable) SDI and
Composite controlled simultaneously
Analog Video -
Video Format Standards:
SMPTE-274M (1080i and 1080p)
SMPTE-296M (720p)
SMPTE-253M (480p, 480i) (reference EIA 770.2 and
770.3)
Number of Analog Outputs:
1 (shared: RGBHV or YPbPr/Composite via breakout
cable)
Connector:
High Density 15-pin D-sub, female
Impedance:
75 ohms, ±10%, 1 Kohm for syncs
Return Loss:
> 20 dB, 30 kHz – 30 MHz
Frequency Response:
Y = 30 kHz – 30 MHz, ± 0.2 dB ripple
PbPr = 30 kHz – 15 MHz, ± 0.2 dB ripple
H/V Sync:
4 Vpp into 1 Mohm, positive polarity
Options available –
Opt 1:
Analog video breakout cable
Connectors:
(5) BNC, male:
R, G, B, Horizontal Sync, Vertical Sync, Pr, Y, Pb, --,
Composite
(1) High density 15-pin D-sub, female
Length:
48 inches
