Audio Output (Dolby E, AES Digital, Analog) Option
78-4043743-01 Rev A 213
THD+N:
< 0.01%
Crosstalk:
< -85 dB
Frequency Response:
20 Hz to 20 KHz < +/-0.1 dBu
Connector:
High density 15-pin D-sub, male
Impedance:
600 ohms nominal
50 ohms min.
Options available –
Audio output (Dolby E, AES Digital,
Analog) option 1:
Audio breakout cable with XLR and Dolby E
BNC
Connectors:
(4) XLR, male; Chan 1 – L,R Chan 2 – L,R
(1) BNC, male; DolbyE
(1) High density 15-pin D-sub, female
Length:
14 inches
Audio output (Dolby E, AES Digital,
Analog) option 3:
Audio breakout cable with unbalanced BNC and
Dolby E BNC
Connectors:
(5) BNC, male; Chan 1 – L,R Chan 2 – L, R Dolby
E
(1) High density 15-pin D-sub, female
Length:
14 inches
Audio output (Dolby E, AES Digital,
Analog) option 4:
Dolby E breakout cable
Connectors:
(1) BNC, male; Dolby E
(1) High density 15-pin D-sub, female
Length:
14 inches
Audio output (Dolby E, AES Digital,
Analog) option 5:
Audio Break Out Cable Terminal Block
Connectors:
(12) Point Screw in Terminal Block; + -
Length:
25 inches
