MPEG-2/MPEG-4 Decoder (1 Video, 2 Audio) Option
78-4043743-01 Rev A 231
Modes (selectable):
User defined, Monitor, Transmission
AV Lip-sync -
Includes control for audio PTS and PCR tracing
Genlock Capability -
Includes Genlock capability for 8704A, 8705 video output card.
Limited support for earlier 8704 and 8706 video output card
(No Color burst phase adjust on NTSC outputs)
HD – Adjustment of pixels and lines. Max number
dependent on video mode
SD – Adjustment of Color burst phase, pixels, and lines.
Genlock Reference
-
Video 1080i @ 25 fps
– Ref 1080i tri-level sync @ 25 fps
– Ref NTSC "black and burst"
Video 1080i @ 29.97
– Ref 1080i tri-level sync @ 29.97 fps
Video 1080i @ 30 fps
– Ref NTSC 1080i tri-level sync @ 30 fps
Video 720p @ 50 fps
– Ref 720p tri-level sync @ 50 fps
– Ref 720p tri-level sync @ 25 fps
Video 720p @ 59.94 fps
– Ref 720p tri-level sync @ 59.94 fps
– Ref 720p tri-level sync @ 29.97 fps
– Ref NTSC "black and burst"
Video 720p @ 60 fps
– Ref 720p tri-level sync @ 60 fps
– Ref 720p tri-level sync @ 30 fps
Video 480i @ 29.97
– Ref NTSC "black and burst"
