Page #201 background image
Configuring Dial Plans
About Dial Plans
Cisco Small Business SPA300 Series, SPA500 Series, and WIP310 IP Phone Administration Guide 199
8
<dialed:substituted>
For sequence substitution, use this format to indicate
that certain dialed digits are replaced by other
characters when the sequence is transmitted. The
dialed digits can be zero or more characters.
EXAMPLE 1:
<8:1650>xxxxxxx
When the user presses 8 followed by a seven-digit
number, the system automatically replaces the dialed 8
with 1650. If the user dials 85550112, the system
transmits 16505550112.
EXAMPLE 2:
<:1>xxxxxxxxxx
In this example, no digits are replaced. When the user
enters a 10-digit string of numbers, the number 1 is
added at the beginning of the sequence. If the user
dials 9725550112, the system transmits
19725550112
,
(comma)
For an intersequence tone, enter a comma between
digits to play an “outside line” dial tone after a user-
entered sequence.
EXAMPLE:
9, 1xxxxxxxxxx
An “outside line” dial tone is sounded after the user
presses 9, and the tone continues until the user
presses 1.
!
(exclamation point)
For number barring, enter an exclamation point to
prohibit a dial sequence pattern.
EXAMPLE:
1900xxxxxxx!
The system rejects any 11-digit sequence that begins
with 1900.
*xx
Enter an asterisk to allow the user to enter a 2-digit star
code.
S0 or L0
For Interdigit Timer Master Override, enter S0 to
reduce the short inter-digit timer to 0 seconds, or enter
L0 to reduce the long inter-digit timer to 0 seconds.
P
For a pause, enter P followed by a number and a space.
The duration of the pause is the specified number of
seconds. This feature is typically used for
implementation of a hot line and warm line, with 0 delay
for the hot line and a non-zero delay for a warm line.
EXAMPLE:
P5
Digit Sequence Function
