OPERATING THE TRANSCEIVER
DATA OPTIONS
90 ENVOY® TRANSCEIVER GETTING STARTED GUIDE
Table 6: Status of the 2.4 kbit/s Data Modem
Colour of LED State Description
Green Solid The transceiver has the modem enabled as a
peripheral device on the GP port.
The modem is enabled and a computer is
communicating with it via VCOM over the
USB–USB connection.
Green Flashing The station is establishing a link, or in a link, with
another station. This station is the receiver of the
link.
