Control Techniques Commander SK User Manual

Introduction Parameter x.00
Parameter
description format
Keypad and
display
CT Modbus RTU
User
programming
CT Soft Menu 0
Advanced parameter
descriptions
16 Commander SK Advanced User Guide
www.controltechniques.com Issue Number: 2
8 Menu 0
Table 8-1 Menu 0 parameters: single line descriptions
Par Description
Default
Corresponding extended
menu parameter
Setting
Eur USA
01 Minimum set speed (Hz) 0.0 Pr 1.07
02 Maximum set speed (Hz) 50.0 60.0 Pr 1.06
03 Acceleration rate (s/100Hz) 5.0 Pr 2.11
04 Deceleration rate (s/100Hz) 10.0 Pr 2.21
05 Drive configuration AI.AV Pr 11.27
06 Motor rated current (A) Drive rating Pr 5.07
07 Motor rated speed (rpm) 1500 1800 Pr 5.08
08 Motor rated voltage (V) 230/400 230/460 Pr 5.09
09 Motor power factor (cos ϕ)0.85Pr 5.10
10 Parameter access L1 Pr 11.44
11 Start/Stop logic select 0 4 Pr 6.04
12 Brake enable diS Pr 12.41
15 Jog reference (Hz) 1.5 Pr 1.05
16 Analog 1 input mode (mA) 4-.20 Pr 7.06
17 Enable negative preset speeds OFF (0) Pr 1.10
18 Preset speed 1 (Hz) 0 Pr 1.21
19 Preset speed 2 (Hz) 0 Pr 1.22
20 Preset speed 3 (Hz) 0 Pr 1.23
21 Preset speed 4 (Hz) 0 Pr 1.24
22 Load display units Ld Pr 4.21
23 Speed display units Fr Pr 5.34
24 Customer defined scaling 1.000 Pr 11.21
25 Security set up 0 Pr 11.30
27 Power up keypad reference 0 Pr 1.51
28 Parameter cloning no Pr 11.42
29 Load defaults no Pr 11.43
30 Ramp mode 1 Pr 2.04
31 Stopping mode 0 Pr 6.01
32 Variable torque select 0 Pr 5.13
33 Catch a spinning motor select OFF (0) Pr 6.09
34 Terminal B7 function select dig Pr 8.35
35 Digital output mode (terminal B3) n=0 Pr 8.41
36 Analog output mode (terminal B1) Fr Pr 7.33
37 Maximum switching frequency (kHz) 3 Pr 5.18
38 Autotune 0 Pr 5.12
39 Motor rated frequency (Hz) 50.0 60.0 Pr 5.06
40 Number of poles Auto Pr 5.11
41 Voltage mode selector Ur I Pr 5.14
42 Low frequency voltage boost (%) 3.0 Pr 5.15
43 Serial comms baud rate 19.2 Pr 11.25
44 Serial address 1 Pr 11.23
45 Software version
Pr 11.29
46 Brake release current threshold (%) 50 Pr 12.42
47 Brake applied current threshold (%) 10 Pr 12.43
48 Brake release frequency (Hz) 1.0 Pr 12.44
49 Brake applied frequency (Hz) 2.0 Pr 12.45
50 Pre-brake release delay (s) 1.0 Pr 12.46
51 Post brake release delay (s) 1.0 Pr 12.47
52 Fieldbus node address 0 Pr 15.03
53 Fieldbus baud rate 0 Pr 15.04
54 Fieldbus diagnostics 0 Pr 15.06
55 Last trip
Pr 10.20
56 Trip before Pr 55 Pr 10.21
