Dalsa Genie Nano Series User Manual

176 • Operational Reference Nano Series GigE Vision Camera
Pixel Size PixelSize Total size in bits of an image pixel.
< RO, Guru >
8 Bits/Pixel Bpp8 Bpp8: 8 bits per pixel
10 Bits/Pixel Bpp10 Bpp10: 10 bits per pixel
12 Bits/Pixel Bpp12 Bpp12: 12 bits per pixel
16 Bits/Pixel Bpp16 Bpp16: 16 bits per pixel
24 Bits/Pixel Bpp24 Bpp24: 24 bits per pixel
32 Bits/Pixel Bpp32 Bpp32: 32 bits per pixel
Horizontal Offset OffsetX Horizontal offset from the Sensor Origin to the Region Of
Interest (in pixels).
< Beginner >
Vertical Offset OffsetY Vertical offset from the Sensor Origin to the Region Of
Interest (in Lines).
< Beginner >
Width Width Width of the Image provided by the device (in pixels).
< Beginner >
Height Height Height of the Image provided by the device (in lines).
< Beginner >
Horizontal Flip ReverseX Horizontal image flip function (available on some models). NA Ver. 1.06
Vertical Flip ReverseY Vertical image flip function (available on some models). Ver. 1.01 Ver. 1.06
Multiple ROI Mode multipleROIMode Enable the Multiple ROI (Region of Interest) per image
feature. The ROI Count is set by the Multiple ROI Count
feature.
< Expert, DFNC >
—
Off Off Single ROI per image.
Active Active The ROI per image feature is active.
ROI Count Horizontal multipleROICountHorizontal Specifies the number of ROI (Region of Interest) available
for the X axis.
< Expert, DFNC >
—
ROI Count Vertical multipleROICountVertical Specifies the number of ROI (Region of Interest) available
for the Y axis.
< Expert, DFNC >
—
ROI Count multipleROICount Specifies the number of possible ROI (Region of Interest)
available in an acquired image. One is minimum, while the
maximum is device specific.
< Expert, DFNC, RO >
ROI Selector multipleROISelector Select an ROI (Region of Interest) when Multiple ROI Mode
is enabled. Selector range is from 1 to the Multiple ROI
Count value.
< Expert, DFNC >
—
ROI (x1, y1) roi1_1 ROI (x1, y1)
ROI (x2, y1) roi2_1 ROI (x2, y1)
ROI (x3, y1) roi3_1 ROI (x3, y1)
ROI (x4, y1) roi4_1 ROI (x4, y1)
