Dalsa Genie Nano Series User Manual

Nano Series GigE Vision Camera Operational Reference • 177
ROI (x1, y2) roi1_2 ROI (x1, y2)
ROI (x2, y2) roi2_2 ROI (x2, y2)
ROI (x3, y2) roi3_2 ROI (x3, y2)
ROI (x4, y2) roi4_2 ROI (x4, y2)
ROI (x1, y3) roi1_3 ROI (x1, y3)
ROI (x2, y3) roi2_3 ROI (x2, y3)
ROI (x3, y3) roi3_3 ROI (x3, y3)
ROI (x4, y3) roi4_3 ROI (x4, y3)
ROI (x1, y4) roi1_4 ROI (x1, y4)
ROI (x2, y4) roi2_4 ROI (x2, y4)
ROI (x3, y4) roi3_4 ROI (x3, y4)
ROI (x4, y4) roi4_4 ROI (x4, y4)
ROI Offset X multipleROIOffsetX Horizontal offset (in pixels) from the origin to the selected
ROI (Region of Interest).
< Expert, DFNC >
ROI Offset Y multipleROIOffsetY Vertical offset (in pixels) from the origin to the selected ROI
(Region of Interest).
< Expert, DFNC >
ROI Width multipleROIWidth Width of the selected ROI (Region of Interest) provided by
the device (in pixels).
< Expert, DFNC >
ROI Height multipleROIHeight Height of the selected ROI (Region of Interest) provided by
the device (in pixels).
< Expert, DFNC >
Binning Selector binningSelector Select how the Horizontal and Vertical Binning is done. The
Binning function can occur in the Digital domain of a device
or at the actual sensor.
< Beginner >
Ver. 1.06
(Available
on some
models)
Ver. 1.03
(Available
on some
models)
Ver. 1.06
NanoXL
—
In Sensor InSensor The Binning function can be done inside the Sensor itself,
which often allows binning to increase the data rate from
the sensor.
In Digital Domain InDigitalDomain The Binning function can be done inside the device but with
a digital processing function. Binning doesn’t affect the
current data rate from the sensor or camera.
Binning Mode binningMode Sets the mode used to combine pixels together when
BinningHorizontal and/or BinningVertical is greater than 1.
< Beginner >
Ver. 1.07
(Available
on some
models)
Ver. 1.07
(Available
on some
models)
Ver. 1.07
NanoXL
—
Sum Sum The responses from the individual pixels are added
together, resulting in increased sensitivity.
Average Average The responses from the individual pixels are averaged,
resulting in increased signal to noise ratio.
