Nano Series GigE Vision Camera Operational Reference • 201
Chunk Exposure
Time
ChunkExposureTime Returns the exposure time used to capture the image.
Guru
Chunk Cycling
Preset Current
Active Set
ChunkCyclingPresetCurrentActiveSet Returns the index of the cycling preset used for this
image.
Guru
Chunk Line
Status All
ChunkLineStatusAll Returns the status of all available line signals, when the
image was exposed. The order is Line1, Line2, ....
Guru
Chunk Gain
Selector
ChunkGainSelector Selects which gain is read by the ChunkGain feature.
Guru
Digital DigitalAll Apply a digital gain adjustment to the entire image. This
independent gain factor is applied to the image after the
sensor.
Sensor SensorAll This gain is applied to the image by the sensor.
Chunk Gain ChunkGain The selected gain value used for the image included in
the payload.
Guru
Chunk Horizontal
Offset
ChunkOffsetX Horizontal offset from the Sensor Origin to the Region Of
Interest (in pixels).
Guru
Chunk Vertical
Offset
ChunkOffsetY Vertical offset from the Sensor Origin to the Region Of
Interest (in lines).
Guru
Chunk Width ChunkWidth Image Width (in pixels) included in the payload.
Chunk Height ChunkHeight Image Height (in lines) included in the payload.
Chunk
Timestamp Value
ChunkTimestamp Returns the 64-bit Timestamp value for the image
included in the payload.
Guru
Chunk Binning
Horizontal
ChunkBinningHorizontal Number of horizontal pixels to combine in the payload
image.
Guru
Chunk Binning
Vertical
ChunkBinningVertical Number of vertical pixels to combine in the payload
image.
Guru
Chunk Frame ID ChunkFrameID
Corresponds to the request_id of an Action_CMD
message.
Guru
Chunk Test
Image Selector
ChunkTestImageSelector The selected test image included in the payload.
Guru
Off Off Image is from the camera sensor.
Grey Horizontal
Ramp
GreyHorizontalRamp Image is filled horizontally with an image that goes from
the darkest possible value to the brightest.
Grey Vertical
Ramp
GreyVerticalRamp Image is filled vertically with an image that goes from the
darkest possible value to the brightest.
Grey Diagonal
Ramp Moving
GreyDiagonalRampMoving Image is filled horizontally and vertically with an image
that goes from the darkest possible value to the brightest
by 1 DN increment per pixel and that moves horizontally
from right to left at each frame by one pixel.
Chunk Serial
Number
ChunkDeviceID Displays the factory set serial number of the device.
Guru
Chunk Device
User ID
ChunkDeviceUserID Returns the user define name of the camera.
Guru
Chunk Pixel
Format
ChunkPixelFormat Pixel format of payload image.
Guru
Monochrome
8-Bit
Mono8 Mono8: Monochrome 8-Bit
Monochrome
10-Bit
Mono10 Mono10: Monochrome 10-Bit
Monochrome
12-Bit
Mono12 Mono12: Monochrome 12-Bit
BayerGR8
8-bit
BayerGR8 Color camera: BayerGR8
BayerRG8
8-bit
BayerRG8 Color camera: BayerRG8
BayerGB8
8-bit
BayerGB8 Color camera: BayerGB8
