RMON Commands 283
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\RMON.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
The following table describes significant fields shown in the display:
Console#
show rmon history
1
other
Sample Set: 1
Interface: gi1/0/1
Requested samples: 50
Owner: Me
Interval: 1800
Granted samples: 50
Maximum table size: 500
Time
-------------------
Jan 18 2005 21:57:00
Jan 18 2005 21:57:30
Dropped
------
3
3
Collisions
----------
0
0
Field Description
Time Date and Time the entry is recorded.
Octets The total number of octets of data (including those in bad
packets and excluding framing bits but including FCS octets)
received on the network.
Packets The number of packets (including bad packets) received during
this sampling interval.
Broadcast The number of good packets received during this sampling
interval that were directed to the broadcast address.
Multicast The number of good packets received during this sampling
interval that were directed to a multicast address. This number
does not include packets addressed to the broadcast address.
Utilization The best estimate of the mean physical layer network
utilization on this interface during this sampling interval, in
hundredths of a percent.
CRC Align The number of packets received during this sampling interval
that had a length (excluding framing bits but including FCS
octets) between 64 and 1518 octets, inclusive, but had either a
bad Frame Check Sequence (FCS) with an integral number of
octets (FCS Error) or a bad FCS with a non-integral number of
octets (Alignment Error).
Undersize The number of packets received during this sampling interval
that were less than 64 octets long (excluding framing bits but
including FCS octets) and were otherwise well formed.
