The following table describes the fields shown in the display.
Field Description
InOctets The number of received octets.
InUcastPkts The number of received unicast packets.
InMcastPkts The number of received multicast packets.
InBcastPkts The number of received broadcast packets.
OutOctets The number of transmitted octets.
OutUcastPkts The number of transmitted unicast packets.
OutMcastPkts The number of transmitted multicast packets.
OutBcastPkts The number of transmitted broadcast packets.
FCS Errors The number of frames received that are an
integral number of octets in length but do not
pass the FCS check.
Single Collision Frames The number of frames that are involved in a
single collision, and are subsequently
transmitted successfully.
Multiple Collision Frames The number of frames that are involved in more
than one collision and are subsequently
transmitted successfully.
SQE Test Errors The number of times that the SQE TEST
ERROR is received. The SQE TEST ERROR is
set in accordance with the rules for verification of
the SQE detection mechanism in the PLS
Carrier Sense Function as described in IEEE
Std. 802.3, 2000 Edition, section 7.2.4.6.
Deferred Transmissions The number of frames for which the first
transmission attempt is delayed because the
medium is busy.
Late Collisions The number of times that a collision is detected
later than one slotTime into the transmission of a
packet.
Excessive Collisions The number of frames for which transmission
fails due to excessive collisions.
Oversize Packets The number of frames received that exceed the
maximum permitted frame size.
