an interface. Use the no form of this command to restore the default
configuration.
Syntax
ip internal-usage-vlan vlan-id
no ip internal-usage-vlan
Parameters
vlan-id—Specifies the internal usage VLAN ID.
Command Mode
Interface Configuration (Ethernet, Port-channel) mode. It cannot be
configured for a range of interfaces (range context).
User Guidelines
An internal usage VLAN is required when an IP interface is defined on an
Ethernet port or Port-channel.
Use this command to define the internal usage VLAN of a port.
If an internal usage VLAN is not defined for a port, the software chooses one
of the unused VLANs.
If a VLAN ID was chosen by the software for internal usage, but it is desired
to use that VLAN ID for a static or dynamic VLAN, do one of the following:
• Remove the IP interface, create the VLAN, and recreate the IP interface.
• Use this command to explicitly define the internal usage VLAN.
Example
The following example reserves unused VLAN 200 as the internal usage
VLAN of Ethernet port 1/3gigabitethernet port 1/0/3.
Console(config)# interface gigabitethernet 1/0/3
Console(config-if)# ip internal-usage-vlan 200
