694 IP Routing Protocol-Independent Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\IP_Routing.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Console>
show ip route address
172.1.1.0 255.255.255.0
longer-
prefixes
Codes: C - connected, S - static, E - OSPF external
S 172.1.1.0/24 [5/3] via 10.0.2.1, 17:12:19, Ethernet1
S 172.1.1.1/32 [5/3] via 10.0.3.1, 19:51:18, Ethernet1
The following table describes the significant fields shown in the display:
Field Description
O The protocol that derived the route.
10.8.1.0/24 The remote network address.
[30/2000] The first number in the brackets is the administrative
distance of the information source; the second number is the
metric for the route.
via 10.0.1.2 The address of the next router to the remote network.
00:39:08 The last time the route was updated, in
hours:minutes:seconds.
Ethernet 1 The interface through which the specified network can be
reached.
