Syntax
policy-map policy-map-name
no policy-map policy-map-name
Parameters
policy-map-name—Specifies the policy map name.
Default Configuration
The default behavior of the policy map is to set the DSCP value to 0 if the
packet is an IP packet, and to set the CoS value to 0 if the packet is tagged.
Command Mode
Global Configuration mode
User Guidelines
Use the policy-map Global Configuration mode command to specify the
name of the policy map to be created, added to, or modified before
configuring policies for classes whose match criteria are defined in a class
map.
Entering the policy-map Global Configuration mode command also enables
configuring or modifying the class policies for that policy map. Class policies
in a policy map can be configured only if the classes have match criteria
defined for them. Use the class-map Global Configuration mode and match
Class-map Configuration mode commands to configure the match criteria for
a class.
The match criteria is for a class. Only one policy map per interface per
direction is supported. The same policy map can be applied to multiple
interfaces and directions.
Example
The following example creates a policy map called Policy1 and enters the
Policy-map Configuration mode.
Console(config)# policy-map policy1
Console(config-pmap)#
