7. Other Field Service Ver. 1.0 Aug. 2005
70
bizhub 200/250/350
Maintenance
7. Remove the screw [12], two connec-
tors [13], and the Operation Board 2
[14].
8. Remove two screws [15] and the
Bracket [16].
9. Remove two screws [17] and the
LCD Board Cover [18].
10. Remove four screws [19] and the
LCD Board [20].
4040F2C762DA
[13]
[14]
[12]
[13]
4040F2C763DA
[15]
[16]
4040F2C764DA
[17]
[18]
4040F2C765DA
[19]
[20]
