7. Jam Display Field Service Ver. 1.0 Aug. 2005
24
PC-102/PC-202
Troubleshooting
7.3.2 Tray3 Paper Take-Up section/Vertical Transport section misfeed (PC-102/
PC-202)
A. Detection timing
B. Action
Type Description
Tray3 Paper Take-Up section/
Vertical transport section
misfeed detection
The leading edge of the paper does not block the Tray3 Vertical Convey-
ance Sensor (PC117-PF) even after the set period of time has elapsed
after the Tray3 Paper Feed Motor (M122-PF) is energized.
The Vertical Conveyance Sensor (PC2) is not blocked even after the
lapse of a given period of time after the Tray3 Vertical Conveyance Sen-
sor (PC117-PF) has been blocked by a paper.
The Tray3 Vertical Conveyance Sensor (PC117-PF) is not unblocked
even after the lapse of a given period of time after PC117-PF has been
blocked by a paper.
Tray3 detection of paper
remaining
The Tray3 Vertical Conveyance Sensor (PC117-PF) is blocked when the
Main Power Switch is set to ON, a door or cover is opened and closed,
or a misfeed or malfunction is reset.
The Tray3 Paper Take-Up Sensor (PC116-PF) is blocked when the Main
Power Switch is set to ON, a door or cover is opened and closed, or a
misfeed or malfunction is reset.
Relevant electrical parts
Tray3 Paper Take-Up Sensor (PC116-PF)
Tray3 Vertical Conveyance Sensor (PC117-PF)
Vertical Conveyance Sensor (PC2)
Tray3 Paper Feed Motor (M122-PF)
Main Control Board (PWB-C2 PF)
Step Action
WIRING DIAGRAM
Control signal
Location (Electrical
components)
1 Initial check items - -
2 PC116-PF sensor check PWB-C2 PF PJ6C2 PF-8 (ON) PC-202 C-4
3 PC117-PF sensor check PWB-C2 PF PJ6C2 PF-11 (ON) PC-202 C-4
4 PC2 sensor check PWB-A PJ22A-9 (ON) D-7
5 M122-PF operation check PWB-C2 PF PJ5C2 PF-1 to 4 PC-202 C-4
6 PWB-C2 PF replacement - -
