Develop ineo 250 - Sensor Layout

6. Jam Display Field Service Ver. 1.0 Aug. 2005
12
Duplex Unit/
Switchback Unit
Troubleshooting
6.2 Sensor layout
[1] Switch Back Unit Sensor PC26 [4] Synchronizing Roller Sensor PC1
[2] Duplex Unit Upper Transport
Sensor
PC24 [5] Duplex Unit Lower Transport
Sensor
PC25
[3] Paper Exit Sensor PC4
4040F4C505DA
[2]
[1]
[3]
[4]
[5]
