9. Jam Display Field Service Ver. 1.0 Aug. 2005
40
FS-508/PU-501/OT-601
Troubleshooting
9.3.5 Finisher Bundle Exit Misfeed
A. Detection Timing
B. Action
Type Description
Finisher Bundle Exit
misfeed detection
The Storage Tray Detecting Sensor (PC8-FN) is not unblocked even after
the set period of time has elapsed after the Exit Motor (M1-FN) is ener-
gized.
Relevant Electrical Parts
Storage Tray Detecting Sensor (PC8-FN)
Exit Motor (M1-FN)
Main Control Board (PWB-A FN)
Step Action
WIRING DIAGRAM
Control Signal
Location
(Electrical Component)
1 Initial check items - -
2 PC8-FN I/O check PWB-A FN PJ13A FN-8 (ON) FS-508 G-8
3 Change PWB-A FN - -
To Next Page
