Develop ineo 250 - C0210 LCT Lift Failure; C0212 LCT Lock Release Failure

8. Trouble code Field Service Ver. 1.0 Aug. 2005
30
PC-402
Troubleshooting
Code Item Description
C0210
LCT Lift Failure
• The Tray Upper Limit Sensor (PC4-LCT) is not blocked
even after the set period of time has elapsed after the
paper lift-up operation began.
• The Tray Upper Limit Sensor (PC4-LCT) is not blocked
even after the set pulse is detected by the Elevator
Motor Pulse Sensor (PC10-LCT) after the paper lift-up
operation began.
• The Tray Lower Position Sensor (PC13-LCT) is not
unblocked even after the set pulse is detected by the
Elevator Motor Pulse Sensor (PC10-LCT) after the
paper lift-up operation began.
• The Tray Upper Limit Sensor (PC4-LCT) is not blocked
even after the set period of time has elapsed after the
paper lift-up operating.
• The Tray Lower Position Sensor (PC13-LCT) is not
blocked even after the set period of time has elapsed
after the paper lift-down operation began.
• The Tray Lower Position Sensor (PC13-LCT) is not
blocked even after the set pulse is detected by the Ele-
vator Motor Pulse Sensor (PC10-LCT) after the paper
lift-down operation began.
• The Tray Upper Limit Sensor (PC4-LCT) is not
unblocked even after the set pulse is detected by the
Elevator Motor Pulse Sensor (PC10-LCT) after the
paper lift-down operation began.
• The Lower Limit Sensor (PC7-LCT) is blocked while
the paper lift-down operating.
C0212 LCT Lock Release Failure
• The drawer cannot be determined to be out of position
even after the set period of time has elapsed after the
Tray Lock Solenoid (SL1-LCT) is energized after the
lowering operation is finished.
C0213 LCT Shift Gate Operation Failure
• The Shift Gate Home Position Sensor (PC14-LCT)
cannot be set to L even after the set period of time has
elapsed after the operation of the Shift Gate Motor
(M3-LCT) began with the Shift Gate Home Position
Sensor (PC14-LCT) set to L.
