Develop ineo 250 - C0213: LCT Shift Gate Operation Failure; C0214: LCT Shift Failure

8. Trouble code Field Service Ver. 1.0 Aug. 2005
34
PC-402
Troubleshooting
8.3.5 C0213: LCT Shift Gate Operation Failure
8.3.6 C0214: LCT Shift Failure
Relevant electrical parts
Shift Gate Home Position Sensor (PC14-LCT)
Shift Gate Motor (M3-LCT)
Main Control Board (PWB-C1 LCT)
Step Action
WIRING DIAGRAM
Control signal
Location
(Electrical com-
ponents)
1
Check the motor and sensor connectors
for proper connection, and correct as
necessary.
--
2
Check the connector of motor for proper
drive coupling, and correct as neces-
sary.
--
3 PC14-LCT sensor check PWB-C1 LCT PJ2H<B> LCT-1 (ON) PC-402 G-6
4 M3-LCT operation check PWB-C1 LCT PJ2H<B> LCT-2 to 3 PC-402 G-6
5 PWB-C1 LCT replacement - -
Relevant electrical parts
Shift Motor Pulse Sensor (PC8-LCT)
Shifter Return Position Sensor (PC11-LCT)
Shifter Home Position Sensor (PC12-LCT)
Main Control Board (PWB-C1 LCT)
Step Action
WIRING DIAGRAM
Control signal
Location
(Electrical com-
ponents)
1
Check the sensor connectors for proper
connection, and correct as necessary.
--
2 PC8-LCT sensor check PWB-C1 LCT PJ2H<A> LCT-3 (ON) PC-402 G-5
3 PC11-LCT sensor check PWB-C1 LCT PJ2H<A> LCT-7 (ON) PC-402 G-4
4 PC12-LCT sensor check PWB-C1 LCT PJ2H<A> LCT-8 (ON) PC-402 G-4
5 PWB-C1 LCT replacement - -
