Develop ineo 250 - Misfeed at Paper Exit Section

8. Jam Display Field Service Ver. 1.0 Aug. 2005
30
DF-605
Troubleshooting
8.3.5 Misfeed at Paper Exit section
A. Detection timing
B. Action
Type Description
Detection of misfeed at
Paper Exit section
The Exit/Turnover Sensor (PC10-ADF) is not blocked even after the set
period of time has elapsed after the Original Detection Sensor (PC8-ADF)
is blocked by the paper.
Detection of paper left in
Paper Exit section
The Exit/Turnover Sensor (PC10-ADF) is not unblocked even after the set
period of time has elapsed after the Original Detection Sensor (PC8-ADF)
is unblocked by the paper.
Relevant Electrical Parts
Transport Motor (M2-ADF)
Original Detection Sensor (PC8-ADF)
Exit/Turnover Sensor (PC10-ADF)
Main Control Board (PBA-CONT)
Step Action
WIRING DIAGRAM
Control Signal
Location
(Electrical Component)
1 Initial check items - -
2 PC8-ADF I/O check PBA-CONT CN6CONT-6 DF-605 G-3
3 PC10-ADF I/O check PBA-CONT CN6CONT-9 DF-605 G-4
4 M2-ADF operation check PBA-CONT CN8CONT-3 to 6 DF-605 C-6
5 Change PBA-CONT - -
