Field Service Ver. 1.0 Aug. 2005 11. Tech. Rep. Mode
169
bizhub 200/250/350Adjustment / Setting
PC7
Tray 1
Tray Set Tray1 Set Sensor Set
Out of
position
PC8
Paper Near
Empty
Tray1 Paper Near-Empty Sensor Unblocked Blocked
PC9 Paper Empty Tray1 Paper Empty Sensor
Paper not
present
Paper
present
PC6
Upper Side
Detect
Tray1 Paper Lift Sensor
At upper
limit
Not at
upper limit
PC11 CD Size 1 Tray1 CD Paper Size Sensor 1
Maximum
value
Not at max-
imum value
PC10 CD Size 2 Tray1 CD Paper Size Sensor 2
Maximum
value
Not at max-
imum value
PWB-I1
FD Size 1
FD Paper Size Board 1
Maximum
value
Not at max-
imum value
FD Size 2
Maximum
value
Not at max-
imum value
FD Size 3
Maximum
value
Not at max-
imum value
FD Size 4
Maximum
value
Not at max-
imum value
PC13
Tray 2
Tray Set Tray2 Set Sensor Set
Out of
position
PC14
Paper Near
Empty
Tray2 Paper Near-Empty Sensor Unblocked Blocked
PC15 Paper Empty Tray2 Paper Empty Sensor
Paper not
present
Paper
present
PC12
Upper Side
Detect
Tray2 Paper Lift Sensor
At upper
limit
Not at
upper limit
PC17 CD Size 1 Tray2 CD Paper Size Sensor 1
Maximum
value
Not at max-
imum value
PC16 CD Size 2 Tray2 CD Paper Size Sensor 2
Maximum
value
Not at max-
imum value
PWB-I2
FD Size 1
FD Paper Size Board 2
Maximum
value
Not at max-
imum value
FD Size 2
Maximum
value
Not at max-
imum value
FD Size 3
Maximum
value
Not at max-
imum value
FD Size 4
Maximum
value
Not at max-
imum value
PC3 2nd Take-up Right Lower Door Sensor
Out of
position
Set
Symbol Panel Display Part/Signal Name
Operation Characteris-
tics/ Panel Display
10
