Field Service Ver. 1.0 Aug. 2005 11. Tech. Rep. Mode
175
bizhub 200/250/350Adjustment / Setting
Symbol Panel Display Part/Signal Name
Operation Characteris-
tics/ Panel Display
10
PC1-PK
Finisher
Punch Scraps Full
Detect
Punch Trash Full Blocked Unblocked
PC22-SK
Home (Paper Hold
R)
Crease Roller Home Position Sensor Blocked Unblocked
S4-FN Middle Guide Transport Jam Detection Switch Close Open
PC20-SK Exit (Saddle) Saddle Exit Sensor
Paper
present
Paper not
present
PC21-SK Saddle Empty Saddle Tray Empty Sensor
Paper
present
Paper not
present
S4-SK Saddle Reset Saddle Interlock Switch Open Close

Staple Home 1
(Saddle)
Staple Home Position Sensor 1 Blocked Unblocked

Self Priming 1
(Saddle)
Self-Priming Sensor 1 Blocked Unblocked

Staple Empty 1
(Saddle)
Staple Empty Detection Sensor 1 Blocked Unblocked

Staple Home 2
(Saddle)
Staple Home Position Sensor 2 Blocked Unblocked

Self Priming 2
(Saddle)
Self-Priming Sensor 2 Blocked Unblocked

Staple Empty 2
(Saddle)
Staple Empty Detection Sensor 2 Blocked Unblocked
PC23-SK
Home (Saddle In &
Out Guide)
In & Out Guide Home Sensor Blocked Unblocked
PC26-SK
Layable Guide
Home (Saddle)
Layable Guide Home Sensor Blocked Unblocked
PC10-MK
Paper Passage 1
(Mail Bins)
Lower Transport Sensor
Paper
present
Paper not
present
PC9-MK
Paper Passage 2
(Mail Bins)
Upper Transport Sensor
Paper
present
Paper not
present
PC11-MK Mail Bin Door Cover Open/Close Sensor Open Close
PC1-MK 1st Mail Bin Empty Paper Detection Sensor 1
Paper not
present
Paper
present
PC5-MK 1st Mail Bin Full Paper Full Detection Sensor 1 Blocked Unblocked
PC2-MK 2nd Mail Bin Empty Paper Detection Sensor 2
Paper not
present
Paper
present
PC6-MK 2nd Mail Bin Full Paper Full Detection Sensor 2 Blocked Unblocked
PC3-MK 3rd Mail Bin Empty Paper Detection Sensor 3
Paper not
present
Paper
present
PC7-MK 3rd Mail Bin Full Paper Full Detection Sensor 3 Blocked Unblocked
PC4-MK 4th Mail Bin Empty Paper Detection Sensor 4
Paper not
present
Paper
present
PC8-MK 4th Mail Bin Full Paper Full Detection Sensor 4 Blocked Unblocked
