19. Malfunction code Field Service Ver. 1.0 Aug. 2005
240
bizhub 200/250/350
Troubleshooting
19.3.5 C0211: Bypass Lifting Motion Failure
19.3.6 C0701: Manual Paper Size Detection Adjustment Failure
19.3.7 C1080: Exit Option Communication Failure
Relevant Electrical Parts
Bypass Pick-Up Solenoid (SL3)
Bypass Lift Sensor (PC29)
Mechanical Control Board (PWB-A)
Power Supply Unit (PU1)
Step Action
WIRING DIAGRAM
Control Signal
Location
(Electrical
Component)
1
Check the SL3 connector for proper connection and
correct as necessary.
--
2 Check cam position. - -
3 PC29 I/O check PWB-A PJ12A-11 (ON) M-14
4 SL3 operation check PWB-A PJ12A-5 (ON) M-13
5 Change PWB-A - -
Relevant Electrical Parts
Bypass Paper Size Detection Unit (VR1) Mechanical Control Board (PWB-A)
Step Action
WIRING DIAGRAM
Control Signal
Location
(Electrical
Component)
1
Check the VR1 connector for proper connection and
correct as necessary.
--
2 Readjust the VR1. - -
3 Replace VR1 - -
4 Change PWB-A - -
Relevant Electrical Parts
Main Control Board (PWB-A FN) Mechanical Control Board (PWB-A)
Step Action
WIRING DIAGRAM
Control Signal
Location
(Electrical
Component)
1
Turn OFF the Main Power Switch, wait for 10 sec. or
more, and turn ON the Main Power Switch.
--
2
Check the PWB-A FN and the PWB-A for proper
connection, and correct as necessary.
--
3 Change PWB-A FN - -
4 Change PWB-A - -
