1. System configuration Field Service Ver. 1.0 Aug. 2005
2
bizhub 200/250/350
General
2/2 System Rear View
*1:The Expanded Memory Unit and Scanner Unit cannot be mounted at the same time.
[1] Machine [5] Dehumidifier Heater 1C
[2] Fax Kit (FK-503) [6] Scanner Unit (SU-501)*2
[3] Fax Multi Line (ML-502) [7]
Expanded Memory Unit
(EM-303/EM-304/EM-305)*2
[4] Local Interface kit (EK-502) [8] Hard Disk (HD-504)
4040T1J504AA
DK-501 PC-202 PC-402
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[1]
To Next Page
