Field Service Ver. 1.0 Aug. 2005 11. Soft Switch List
133
FK-503Adjustment / Setting
NOTE
• The features with (*) are settable by users. *: Screen setting
MODE Factory setting bit
419
Bit: 7654 3210
0100 0000
HEX:40
Bit Feature
Logic
Description
01
7 Select a copy output bin. * Bit7-6: 00 First tray out-
put
• Specify a tray to
where printed docu-
ment is delivered to
when the finisher is
attached.
• “Additional bin output”
is valid only when the
additional bin is
attached.
6
01 Second tray
output
10 Additional bin
output
11 Not available
5 Select a FAX (G3-2) out-
put bin. *
Bit5-4:
00 First tray
output
• Specify a tray to
where FAX (G3-2)
document is delivered
to when the finisher
has been attached.
• “Additional bin output”
is valid only when the
additional bin is
attached.
4 01 Second tray
output
10 Additional bin
output
11 Not available
3 Select a FAX (network)
output bin. *
Bit3-2:
00 First tray
output
2 01 Second tray
output
10 Additional bin
output
11 Not available
1 Select FAX (G3-2) output
bin. *
Bin 1 Bin 2 Specify a bin to where FAX (G3-2) docu-
ment is delivered when the job separator
has been attached.
0 Select FAX (network) out-
put bin. *
Bin 1 Bin 2 Specify a bin to where FAX (network)
document is delivered when the job sep-
arator has been attached.
To Next Page
