Field Service Ver. 1.0 Aug. 2005 11. Soft Switch List
135
FK-503Adjustment / Setting
MODE Factory setting bit
422
Bit: 7654 3210
0000 1000
HEX:08
Bit Feature
Logic
Description
01
7 Total counter. Bit 7-6:
00 Mode 1 (std) Specifies a counting
method of total counter.
6 01 Mode 2
10 Mode 3
Others Not available
5 Size counter. Bit 5-3: 000 Do not count Specifies sizes of papers
to be counted by size
counter.
4
3
001 A3, 11x17
010 A3, B4,
11×17, Legal
011 A3, B4, FLS,
11×17, Legal,
11×14
100 A6
Others Not available
2 Copy Kit counter. (Copy) Bit 2-1:
00 Mode 1
(Do not count)
Select whether to set
counting or not for
the Copy Counter
and select whether
to inhibit the initiation
of a new copy cycle
or not when the cur-
rent value reaches
the set value.
1
01 Mode 2 (Counted
and permits copy-
ing even when
the set value is
reached.)
10 Mode 3 (Counted
and inhibits copy-
ing when the set
value is reached.)
11 Not available
To Next Page
