Field Service Ver. 1.0 Aug. 2005 1. Product specifications
3
DF-605General
F. Mixed original feed chart
For Metric
For Inch
G. Machine specifications
H. Operating
• Conforms to the operating environment of the main unit.
NOTE
• These specifications are subject to change without notice.
Max. Original
Size
297 mm 257 mm 210 mm 182 mm 148 mm
Mixed Original Size A3 A4 B4 B5 A4R A5 B5R A5R
297 mm
A3 OKOK------
A4 OKOK------
257 mm
B4 OK OK OK OK - - - -
B5 OK OK OK OK - - - -
210 mm
A4R OK* OK* OK OK OK OK - -
A5 NG NG OK OK OK OK - -
182 mm B5R NG NG OK* OK* OK OK OK -
148 mm A5R NGNGNGNGNGNGOKOK
123 mm B6R NGNGNGNGNGNGNGOK
Max. Original Size 11 8.5 5.5
Mixed Original Size 11 x 17 8.5 x 11 8.5 x 14 8.5 x 11R 5.5 x 8.5 8.5 x 5.5R
11
11 x 17 OK OK - - - -
8.5 x 11 OK OK - - - -
8.5
8.5 x 14 OK* OK* OK OK OK -
8.5 x 11R OK* OK* OK OK OK -
5.5
8.5 x 5.5 NG NG OK OK OK -
8.5 x 5.5R NG NG NG NG NG OK
OK
Mixed Original Feed available
(Tilted with in 1.5% or less)
NG NO. Mixed Original Feed
- Can not Set Original
* Tilted with in 2% or less is 80%
Power Requirements
DC 24 V (supplied from the main unit)
DC 5 V (generated within the Automatic Document Feeder)
DC 3.3 V (supplied from the main unit)
Max. Power Con-
sumption
48 W or less
Dimensions
582 (W) x 558 (D) x 145 (H) mm
23 inch (W) x 20.5 inch (D) x 5.75 inch (H)
Weight 10 kg (22 lb) or less
