8. Trouble code Field Service Ver. 1.0 Aug. 2005
32
PC-402
Troubleshooting
8.3 Solution
8.3.1 C0001: LCT communication error
8.3.2 C0209: LCT Elevator Motor Failure
Relevant electrical parts
Main Control Board (PWB-C1 LCT)
Step Action
WIRING DIAGRAM
Control signal
Location
(Electrical com-
ponents)
1 Turn the main unit off, then on again. - -
2 PWB-C1 LCT replacement - -
Relevant electrical parts
Elevator Motor (M5-LCT)
Elevator Motor Pulse Sensor (PC10-LCT)
Interface Board (PWB-H LCT)
Main Control Board (PWB-C1 LCT)
Step Action
WIRING DIAGRAM
Control signal
Location
(Electrical com-
ponents)
1
Check the motor and sensor connectors
for proper connection, and correct as
necessary.
--
2
Check the connector of motor for proper
drive coupling, and correct as neces-
sary.
--
3 PC10-LCT sensor check PWB-C1 LCT PJ2H<A> LCT-5 (ON) PC-402 G-5
4 M5-LCT operation check PWB-C1 LCT PJ2H<B> LCT-6 to 7 PC-402 G-6
5 PWB-H LCT replacement - -
6 PWB-C1 LCT replacement - -
