10.2.3 C11A5: Saddle In & Out Guide Motor Failure
10.2.4 C11A6: Saddle Layable Guide Drive Failure
Relevant Electrical Parts
In & Out Guide Motor (M13-SK)
In & Out Guide Home Sensor (PC23-SK)
Main Control Board (PWB-C SK)
Step Action
WIRING DIAGRAM
Control Signal
Location
(Electrical Component)
1
Check the M13-SK connector for
proper connection and correct as
necessary.
--
2
Check M13-SK for proper drive cou-
pling and correct as necessary.
--
3 M13-SK operation check PWB-C SK PJ4C SK-4 to 5 SD-502 H-6
4 PC23-SK I/O check PWB-C SK PJ10C SK-3 (ON) SD-502 B-4
5 Change PWB-C SK - -
Relevant Electrical Parts
Layable Guide Motor (M14-SK)
Layable Guide Home Sensor (PC26-SK)
Main Control Board (PWB-C SK)
Step Action
WIRING DIAGRAM
Control Signal
Location
(Electrical Component)
1
Check the M14-SK connector for
proper connection and correct as
necessary.
--
2
Check M14-SK for proper drive cou-
pling and correct as necessary.
--
3 M14-SK operation check PWB-C SK PJ4C SK-8 to 9 SD-502 H-6
4 PC26-SK I/O check PWB-C SK PJ10C SK-6 (ON) SD-502 B-4
5 Change PWB-C SK - -
