C
HAPTER
3
| Using the Web Interface
Navigating the Web Browser Interface
ā 60 ā
Neighbors Displays LLDP information about a remote device connected
to a port on this switch
237
LLDP-MED
Neighbors
Displays information about a remote device connected to a
port on this switch which is advertising LLDP-MED TLVs,
including network connectivity device, endpoint device,
capabilities, application type, and policy
238
Port Statistics Displays statistics for all connected remote devices, and
statistics for LLDP protocol packets crossing each port
241
MAC Table Displays dynamic and static address entries associated with
the CPU and each port
242
VLANs Virtual LANs 243
VLAN Membership Shows the current port members for all VLANs configured by
a selected software module
243
VLAN Port Shows the VLAN attributes of port members for all VLANs
configured by a selected software module which uses VLAN
management, including PVID, VLAN aware, ingress filtering,
frame type, egress filtering, and PVID
244
Diagnostics 247
Ping Tests specified path using IPv4 ping 247
Ping6 Tests specified path using IPv6 ping 247
VeriPHY Performs cable diagnostics for all ports or selected port to
diagnose any cable faults (short, open etc.) and report the
cable length
248
Maintenance 251
Restart Device Restarts the switch 251
Factory Defaults Restores factory default settings 252
Software Upload Updates software on the switch with a file specified on the
management station
252
Configuration 253
Save Saves configuration settings to a file on the management
station
253
Upload Restores configuration settings from a file on the
management station
253
Table 4: Main Menu (Continued)
Menu Description Page
