C
HAPTER
3
| Using the Web Interface
Navigating the Web Browser Interface
– 59 –
Port Shows the entries authorized by port security services,
including MAC address, VLAN ID, the service state, time
added to table, age, and hold state
208
NAS Shows global and port settings for IEEE 802.1X
Switch Shows port status for authentication services, including
802.1X security state, last source address used for
authentication, and last ID
209
Port Displays authentication statistics for the selected port –
either for 802.1X protocol or for the remote authentication
server depending on the authentication method
210
ACL Status Shows the status for different security modules which use
ACL filtering, including ingress port, frame type, and
forwarding action
214
DHCP Dynamic Host Configuration Protocol
Snooping
Statistics
Shows statistics for various types of DHCP protocol packets 215
Relay
Statistics
Displays server and client statistics for packets affected by
the relay information policy
217
ARP Inspection Displays entries in the ARP inspection table, sorted first by
port, then VLAN ID, MAC address, and finally IP address
219
IP Source Guard Displays entries in the IP Source Guard table, sorted first by
port, then VLAN ID, MAC address, and finally IP address
219
AAA Authentication, Authorization and Accounting 220
RADIUS
Overview
Displays status of configured RADIUS authentication and
accounting servers
220
RADIUS Details Displays the traffic and status associated with each
configured RADIUS server
221
LACP Link Aggregation Control Protocol 225
System Status Displays administration key and associated local ports for
each partner
225
Port Status Displays administration key, LAG ID, partner ID, and partner
ports for each local port
226
Port Statistics Displays statistics for LACP protocol messages 227
Spanning Tree 228
Bridge Status Displays global bridge and port settings for STA 228
Port Status Displays STA role, state, and uptime for each port 230
Port Statistics Displays statistics for RSTP, STP and TCN protocol packets 231
IGMP Snooping Displays statistics related to IGMP packets passed upstream
to the IGMP Querier or downstream to multicast clients
232
MLD Snooping Multicast Listener Discovery Snooping 234
Status Displays MLD querier status and protocol statistics 234
Group Information Displays active MLD groups 234
MVR Shows statistics for IGMP protocol messages used by MVR;
also shows information about the interfaces associated with
multicast groups assigned to the MVR VLAN
235
LLDP Link Layer Discovery Protocol 237
Table 4: Main Menu (Continued)
Menu Description Page
